KTR扭力型联轴器TOOLFLEX®S系列选型参数
英文样本介绍:
TOOLFLEX® is a torsionally stiff, flexible metal bellow coupling with a bellow from stainless steel and coupling hubs from aluminium (in size 55 and 65 as well as with type KN the coupling hubs are from steel). The metal bellow compensates perfectly for axial, radial and angular displacements. At the same time its geometric shape allows for high torsional stiffness and a low mass moment of inertia.
In addition it is resistant to media influences and critical operating conditions. For different applications and assemblies the TOOLFLEX offers various hub designs as well as two different bellow lengths. The combination of these single parts forms one type.
Balganbindungen
The connection between bellow and hub is guaranteed by three different designs, dependent on the size. As for size 5 to size 12 the bellow is glued to the coupling hub, therefore ambient temperatures from -30° C to +100° C are permissible for these TOOLFLEX sizes. As for size 16 to size 45 the bellow-shaft connection is guaranteed by a flanged connection making sure for a torque transmission with each single bellow layer. The bellow-hub connection of the TOOLFLEX 55 and 65 is guaranteed through a welding connection.
KTR扭力型联轴器TOOLFLEX®S系列选型参数
扭力型联轴器中文样本介绍:
波纹管和集线器之间的连接由三种不同的设计保证,具体取决于尺寸。对于尺寸5尺寸12,波纹管胶合到联轴器毂,因此这些TOOLFLEX尺寸允许-30°C+ 100°C的环境温度。对于尺寸为16到45的波纹管,通过法兰连接确保波纹管轴连接,确保每个单个波纹管层的扭矩传递。通过焊接连接保证TOOLFLEX 55和65的波纹管轮毂连接。
TOOLFLEX®是一种扭转刚性的柔性金属波纹管联轴器,带有不锈钢波纹管和铝合金连接毂(尺寸55和65,以及KN型,联轴器轮毂均为钢)。
KTR扭力型联轴器TOOLFLEX®S系列选型参数
