| 规格 | DLM10-10A/AG |
|---|---|
| 扭矩 | 100 |
| 重量 | 5.5 |
| 转速 | 3000 |
| 品牌 | 冠海 |
| 型号 | DLM10-10A/AG |
·干湿两用、应用场合广泛。
·磁通不过片式、空载低、响应迅速。
·可调整、寿命长。
·传递力矩大，运转平稳。
性能参数：Main Technical Data
规格
Size | 额定动力矩 Rated Dynamic Torque N.m | 额定静力矩 Rated Static Torque N.m | 空载力矩 Drag Torque (≤)N.m | 接通时间 Engagement Time (≤)S | 断开时间 Disengagement Time (≤)S | 额定电压 Rated Voltage D.C V | 线圈功率 Coil Consumption (20℃)W | **高转数 Max Revolutions r.p.m | 重量 Weight Kg |
1A/1AG | 12.5 | 20/14 | 0.088/0.05 | 0.14/0.11 | 0.025 | 24 | 26 | 3000 | 2 |
2A/2AG | 25 | 40/27.5 | 0.175/0.1 | 0.18/0.16 | 0.028 | 24 | 27 | 3000 | 2.6 |
4A/4AG | 40 | 63/44 | 0.28/0.16 | 0.2/0.18 | 0.03 | 24 | 33 | 3000 | 3.2 |
6A/6AG | 63 | 100/70 | 0.35/0.26 | 0.25/0.2 | 0.04 | 24 | 43 | 3000 | 4 |
10A/10AG | 100 | 160/110 | 0.5/0.35 | 0.28/0.25 | 0.045 | 24 | 43 | 3000 | 5.5 |
16A/16AG | 160 | 250/175 | 1/0.56 | 0.3/0.28 | 0.06 | 24 | 47 | 2500 | 7.8 |
25A/25AG | 250 | 400/280 | 1.5/0.88 | 0.35/0.30 | 0.08 | 24 | 55 | 2200 | 11 |
40A/40AG | 400 | 630/440 | 2.5/1.4 | 0.4/0.35 | 0.11 | 24 | 62 | 2000 | 15 |
63A/63AG | 630 | 1000/700 | 4/2.2 | 0.5/0.4 | 0.12 | 24 | 70 | 1750 | 21 |
100A/100AG | 1000 | 1600/1100 | 6/3 | 0.6/0.5 | 0.15 | 24 | 79 | 1600 | 32 |
160A/160AG | 1600 | 2500/1750 | 10/5.5 | 0.9/0.7 | 0.18 | 24 | 93 | 1350 | 50 |
250A/250AG | 2500 | 4000/2750 | 15/8.6 | 1.15/.09 | 0.25 | 24 | 110 | 1200 | 77 |
400A/400AG | 4000 | 6300/4400 | 24/14 | 1.3/1.2 | 0.3 | 24 | 123 | 1000 | 122 |
630A/630AG | 6300 | 10000/7000 | 40/25 | 1.4/1.3 | 0.35 | 24 | 154 | 900 | 194 |
1000A/1000AG | 10000 | 16000/11000 | 64/35 | 1.6/1.5 | 0.4 | 24 | 175 | 750 | 300 |
