品牌：TN
材质：轴承钢
适用范围：工业
起订：10000个
供应：10000个
| 材质 | 轴承钢 |
|---|---|
| 适用范围 | 工业 |
| 用途 | 工业 |
| 品牌 | 天牛 |
| 型号 | ZZ ZZ...2RS ZZ P...2RS ZZ...P ZZ...PP |
| 加工定制 | 是 |
| Freewheel Size | Maximum torque MN | Nominal torque MN | Maximum speed | Load rating of bearing support | Bored | B | D | K | Weight | ||||||||||
| Dynamic C | statiC0 | ||||||||||||||||||
| Lb-ft | Nm | Lb-ft | Nm | rpm | Lbf | N | Lbf | N | inch | mm | inch | mm | inch | mm | inch | mm | lbs | kg | |
| ZZ8 | 3.8 | 5.0 | 1.9 | 2.5 | 15000 | 720 | 3200 | 194 | 860 | 0.315 | 8 | 0.354 | 9 | 0.866 | 22 | 1.063 | 27 | 0.05 | 0.02 |
| ZZ6201 | 13.8 | 18.6 | 6.9 | 9.3 | 10000 | 1370 | 6100 | 610 | 2700 | 0.472 | 12 | 0.394 | 10 | 1.260 | 32 | 1.535 | 39 | 0.09 | 0.04 |
| ZZ6202 | 38.6 | 52.0 | 19.3 | 26.0 | 9400 | 1350 | 6000 | 830 | 3700 | 0.591 | 15 | 0.433 | 11 | 1.378 | 35 | 1.654 | 42 | 0.14 | 0.06 |
| ZZ6203 | 50.4 | 68.0 | 25.2 | 34.0 | 8200 | 1650 | 7350 | 1025 | 4550 | 0.669 | 17 | 0.472 | 12 | 1.575 | 40 | 2.008 | 51 | 0.18 | 0.08 |
| ZZ6204 | 96.2 | 130.0 | 48.1 | 65.0 | 6800 | 2250 | 10000 | 1415 | 6300 | 0.787 | 20 | 0.551 | 14 | 1.850 | 47 | 2.283 | 58 | 0.26 | 0.12 |
| ZZ6205 | 118.6 | 160.0 | 59.3 | 80.0 | 5600 | 2475 | 11000 | 1575 | 7000 | 0.984 | 25 | 0.591 | 15 | 2.047 | 52 | 2.480 | 63 | 0.33 | 0.15 |
| ZZ6206 | 251.8 | 340.0 | 125.9 | 170.0 | 4000 | 3375 | 15000 | 2250 | 10000 | 1.181 | 30 | 0.630 | 16 | 2.441 | 62 | 2.874 | 73 | 0.55 | 0.25 |
| ZZ6207 | 259.2 | 350.0 | 129.6 | 175.0 | 3600 | 2810 | 12500 | 1620 | 7200 | 1.378 | 35 | 0.669 | 17 | 2.835 | 72 | 3.346 | 85 | 0.66 | 0.30 |
| ZZ40 | 481.4 | 650.0 | 240.7 | 325.0 | 3000 | 3485 | 15500 | 2755 | 12250 | 1.575 | 40 | 0.866 | 22 | 3.150 | 80 | 3.710 | 94 | 1.10 | 0.50 |
